The PE series jaw crushers adopt a simple structure, a deep crushing cavity, an integrally welded frame and an optimized movement style of the movable jaw, so the equipment performance has been significantly improved over the traditional jaw crushers to achieve more stable and reliable operation.
Factory Price If you want to know how to choose or design the jaw crusher, please contact us, we will give our most professional suggestions or design.
The PE jaw crusher has been developed over centuries of refinement and integrates advanced technology, resulting in improved stability and reliability in its performance.
This crusher is constructed with high manganese steel castings to enhance the lifespan of core components. Additionally, it features an auto-stop setting that prevents damage caused by overloading.
Each PE jaw crusher is precisely processed for strength and rigidity. The accurate blanking ensures proper weights and structures for the flywheel and grooves, contributing to improved operational balance.
SBM's PE jaw crusher is developed based on years of accumulated expertise, making its performance highly reliable.
| Model | Maximum feeding size (mm) | Output Size (mm) | Capacity (t/h) | Power (kW) |
|---|---|---|---|---|
| PE500×750 | 425 | 50-100 | 45-100 | 55 |
| PE600×900 | 500 | 65-160 | 90-180 | 55-75 |
| PE750×1060 | 630 | 80-140 | 130-260 | 90-110 |
| PE900×1200 | 750 | 95-200 | 220-380 | 132 |
| PE1000×1200 | 850 | 195-265 | 280-500 | 132 |
| PE1200×1500 | 1020 | 150-300 | 460-900 | 200 |
